Set up HP laserjet 1020 printer on linux

1 minute read

Background

most Linux distributions has printer driver by default, for HP, it is HPLIB, but there an addition plugin which is close source needed for this 1020 printer, when installing this plug-in, I counter some problems, and I will describe it later.

Problem

print error

hp laserjet 1020, hpcups 3.17.10, requires proprietary plugin

Solution 1 hpip

  1. install hplip

sudo apt-get install hplip hplip-gui

  1. refer this to install plugin:
    1. connect the printer and type command ` hp-plugin`
    2. follow GUI and automatically download the plugin, but there is a 404 problem for me, many be caused by my network(I am in China, LOL). so you need manually download the plugin and install it.
    3. you can manually download xxx.plugin file here, and load it from local file to HPLIB by hp-plugin command.
    4. enjoy it!

Solution 2 foo2zjs

foo2zjs is an open source laib for printer, and it work well on HP 1020.

  1. remove HPLIBsudo apt-get remove --assume-yes hplip hpijs hplip-cups hplip-data libhpmud0 foomatic-db-hpijs

  2. make install foo2zjsby
    sudo apt-get install cupsys-bsd foo2zjs make build-essential
    wget http://support.ideainformatica.com/hplj1020/foo2zjs-patched.tar.gz
    tar zxvf foo2zjs-patched.tar.gz
    cd foo2zjs
    make
    sudo make install
    sudo make install-udev
    sudo udevstart

  3. plug the printer and run sudo /etc/init.d/cupsys restart

  4. to make plain (lpr) text print nicely, run

     sudo lpoptions -o cpi-12 -o lpi=7 -o page-left=36 -o page-right=36 -o page-top=36 -o page-bottom=36

  5. open system printer manager and set up HP printer model as foo2zji by changing the model form foo2zjs/ppd and select the xxx.ppd for your printer.

  6. if there any problem, you many modify the ppd file manually, e.g. change the Default page size to A4 from “Letter”

    sudo gedit xxx/ppd/LaserJet-1020.ppd

  7. enjoy it!
